Introduction
The morbidity and mortality of COVID-19 are higher in men than women, whereas the incidence is only slightly higher in women.1 The gender disparity indicates a potential role of androgen and/or estrogen in the regulation of viral infection in target cells and in the host immune response. SARS-CoV-2 viral entry into host cells is mediated by the interaction between the viral spike (S) protein and two host cell-surface molecules: receptor angiotensin-converting enzyme 2 (ACE2) and S protein primer transmembrane serine protease 2 (TMPRSS2). TMPRSS2 cleaves the S protein and allows the activated S protein to bind to its receptor ACE2. Furin, another cell-surface protease, is also involved in S protein priming by cleaving the S protein on a second proteolytic site.2 TMPRSS2 is known to be transcriptionally upregulated by androgen in the human prostate and in prostate cancer (PCa). Approximately 40% of human PCa harbors a translocation between the TMPRSS2 and ERG genes, leading to androgen-dependent overexpression of ERG oncoprotein. In early 2020, a study from Italy showed that PCa patients on androgen deprivation therapy (ADT) had a significantly lower incidence of COVID-19 compared to PCa patients not on ADT.3
Based on the above evidence, we hypothesized that ADT may be able to suppress SARS-CoV-2 viral entry into target cells through the downregulation of TMPRSS2 and perhaps ACE2 and furin. Two phase 2 randomized, double-blind, placebo-controlled clinical trials, including our “Hormonal Intervention for the Treatment in veterans with COVID-19 requiring Hospitalization (HITCH)” study (ClinicalTrials.gov Identifier: NCT04397718), failed to demonstrate that rapid suppression of serum androgen levels to a castrate range affected the clinical outcomes of men hospitalized for COVID-19.4,5 During the trial, several independent studies reported preclinical evidence in animal models and cell lines that androgen deprivation or androgen receptor (AR) antagonists reduce SARS-CoV-2 host cell entry.6–8 In this study, we aimed to critically evaluate the role of androgen in regulating TMPRSS2, ACE2, and furin protein expression in the upper and lower respiratory tract epithelium.
Methods
Cell lines, xenografts, and patient-derived xenograft (PDX) models
The cell lines used in this study (LNCaP, A549, H441, H2170) were purchased from the American Type Culture Collection (Manassas, VA, USA) and cultured in the recommended media. 16D cells were obtained from Dr. Amina Zoubeidi (Vancouver Prostate Centre, BC, Canada) and maintained as previously described. The cells were grown on plates coated with 0.01% poly-L-lysine (Sigma; St. Louis, MO, USA) to enhance attachment. Enzalutamide (Selleck Chemicals; Houston, TX, USA; 10 µM) or apalutamide (Janssen Research & Development; Titusville, NJ, USA; 10 µM), was replenished every other day for the period specified in each figure. For the castration experiments, the cells were cultured in media supplemented with charcoal-stripped fetal bovine serum (Sigma). LNCaP cells were used for the subcutaneous xenograft injections within four passages. Six-week-old male ICR/scid mice (Taconic Biosciences, Germantown, NY, USA) were injected subcutaneously with 5 million LNCaP cells in 100% Matrigel to generate LNCaP xenografts. The BID-PC-1 PDX was passaged in intact male ICR/scid mice and was hormone-sensitive. Xenograft and PDX tumors were grown until they reached a volume of approximately 1,000 mm3, and then the mice were castrated, or castrated and placed on enzalutamide (50 mg/kg/day) in drinking water. Seven days following castration or castration+enzalutamide, the mice were euthanized and the tumors were harvested.
Mouse experiments
Male C57BL/6J and C57BL/6N mice (B6) were purchased from Jackson Laboratories (Bar Harbor, ME, USA) and housed under the care and supervision of veterinarians from the Division of Laboratory Animal Medicine at the University of California, Los Angeles (USA). The mice were treated with either 10 mg/kg/day enzalutamide (Selleck Chemicals; S1250) p.o., 50 mg/kg/day bicalutamide (Santa Cruz Biotechnology, Santa Cruz, CA, USA; sc-202976A) i.p., or vehicle. The vehicle used was 1% carboxymethyl cellulose (Sigma; 419273), 0.5% Tween 80 (Fisher Scientific, Waltham, MA, USA; BP338-500), and 5% dimethyl sulfoxide (Fisher Scientific; BP231-100) for enzalutamide, and 100% dimethyl sulfoxide for bicalutamide. Castrated mice were purchased from Jackson Laboratories. The lungs, prostate, and head/nose portions were dissected, fixed in formalin, decalcified using Immunocal (StatLab, McKinney, TX, USA; 1414-32) if containing bones, and prepared for paraffin sections. Half of those organs were lysed with radioimmunoprecipitation assay buffer (Thermo Scientific; 89901) with protease inhibitor (Sigma; CO-RO) and phosphatase inhibitor (Thermo Scientific; 78428) for protein analysis. For the protein extract of the nasal mucosa, the skull was taken off from the posterior part of the body and the mandible. The skin, muscle, and brain were removed from the skull, and the remaining mucosal tissue and bone were submerged in lysis buffer and mixed by vortexing. After 30 min of incubation on ice, the lysis buffer was collected and sonicated. For immunostaining, the tissue was fixed with 4% paraformaldehyde in phosphate-buffered saline (diluted from 16% solution; Electron Microscopy Sciences, Hatfield, PA, USA; 15710) for 6–8 h at room temperature and then processed for paraffin sections. For mouse prostate immunohistochemistry (IHC) following abiraterone and enzalutamide treatment, the ICR/scid male mice were maintained at the animal facility at the Beth Israel Deaconess Medical Center (Boston, MA, USA). The mice were given abiraterone acetate (30 mg/kg/day) or enzalutamide (50 mg/kg/day) in drinking water for 10 days. Following the 10-day treatment, the mice were euthanized. The prostate with attached seminal vesicles was dissected out, fixed with 4% paraformaldehyde in phosphate-buffered saline, and then processed for paraffin sections.
This study was carried out in accordance with the recommendations in the Guide for the Care and Use of Laboratory Animals of the National Institutes of Health. The protocol was approved by the Animal Research Committee on the Ethics of Animal Experiments of the University of California at Los Angeles (Protocol Number: ARC-2017-020). All surgeries were performed under sodium pentobarbital anesthesia, and all efforts were made to minimize suffering.
Western blot and RNA sequencing
Cells were lysed in radioimmunoprecipitation assay buffer (50 mM Tris-HCl pH 8.0, 150 mM NaCl, 1% NP-40, 0.5% sodium deoxycholate, 0.1% sodium dodecyl sulfate; Fisher Scientific) containing a complete protease inhibitor cocktail tablet (Roche, Indianapolis, IN, USA) and Halt Phosphatase Inhibitor (Fisher Scientific). Each sample was sonicated for 40 s at 20 kHz with a sonic dismembrator (Fisher Scientific) to improve the membranous and nuclear protein yield. Samples were run on NuPAGE 4–12% Bis-Tris Gel (Invitrogen, Waltham, MA, USA) and transferred onto 0.45-µm polyvinylidene fluoride membranes (Millipore Sigma, Burlington, MA, USA). Total protein was visualized using SYPRO RUBY protein blot stain (Fisher Scientific), and membranes were blocked in phosphate-buffered saline + 0.1% Tween-20 (Fisher Scientific) + 5% milk (Fisher Scientific) for 1 h. The membranes were probed overnight at 4°C with the following primary antibodies: prostate-specific antigen (PSA; Cell Signaling Technology, Danvers, MA, USA; 5877, 1:1,000), TMPRSS2 (Abcam; Waltham, MA, USA; 92323, 1:1,000), vinculin (Abcam; 129002, 1:6,000), AR (Cell Signaling Technology; 5153, 1:2,000), furin (Abcam; 183495, 1:1,000), glyceraldehyde 3-phosphate dehydrogenase (GeneTex; Irvine, CA, USA; GT239, 1:10,000). The membranes were then incubated with chromophore-conjugated secondary antibodies (Fisher Scientific) or horseradish peroxidase-conjugated secondary antibodies (Fisher Scientific) for 1 h and detected via florescence or horseradish peroxidase chemiluminescence using an Amersham ECL Prime Western Blotting Detection Reagent (Fisher Scientific), respectively. For RNA sequencing, RNA was extracted from 16D cells treated with dimethyl sulfoxide or 10 µM enzalutamide for 48 h using a RNeasy Mini Kit (Qiagen; Germantown, MD, USA). Library preparation was performed using the KAPA Stranded mRNA-Seq Kit (Roche). The workflow consists of mRNA enrichment, cDNA generation, and end repair to generate blunt ends, A-tailing, adaptor ligation, and polymerase chain reaction amplification. Different adaptors were used for multiplexing samples in one lane. The Illumina HiSeq 3000 was used to perform sequencing for 1 × 50 runs. The data have been deposited in NCBI’s Gene Expression Omnibus and are accessible through GEO Series accession number GSE202885.
IHC
Tissue sections (3 µm) were subjected to immunohistochemical staining. The sections were stained using anti-TMPRSS2 (clone EPR3861, rabbit, Abcam; 1:16,000), anti-TMPRSS2 (obtained from the Peter Nelson Lab, University of Washington, Seattle, WA, USA; mouse; 1:200), anti-AR (clone SP107, rabbit, Cell Marque, Rocklin, CA, USA; 1:100), anti-AR (441, mouse, Santa Cruz, 1:100), anti-ACE2 (clone MM0073-11A31, mouse, Abcam, 1:200), anti-ACE2 (ab15348, rabbit, Abcam, 1:100), and anti-furin (EPR14674, rabbit, Abcam, 1:600). IHC was carried out on a Dako Link 48 autostainer (Agilent Technologies, Santa Clara, CA, USA), with antibody incubation for 60 min, amplification using Envision FLEX rabbit or mouse linkers, and visualization using the Envision Flex High-sensitivity visualization system (Agilent Technologies).
Nasopharyngeal (NP) swabs
The NP swab specimens obtained from the HITCH subjects were placed in viral transport media and then centrifuged to remove the supernatant fluid. The cell pellets were transferred to a 1.5-mL Eppendorf tube. One drop of warmed HistoGel heated at 42°C was added to each pellet. A clot formed within 3–5 min. The clot was then processed by routine formalin-fixation and paraffin-embedding for histology.
Statistical analysis
Prism v8.3.0 (GraphPad; San Diego, CA, USA) was used to generate graphs and perform statistical analyses. All t-tests conducted were two-sided t-tests with Welch’s correction. All error bars represent the standard error of the mean. A p-value of <0.01 was considered statistically significant.
Results
Androgen has a minimal effect on TMPRSS2 protein expression in murine or human PCa
Although TMPRSS2 is a canonical AR target in human PCa, it is still unknown whether TMPRSS2 expression is exclusively regulated by androgen in prostate tissue and PCa. To examine the dependency of androgen regulation in TMPRSS2 expression, we assessed the changes in TMPRSS2 protein expression in prostate glands of male mice after ADT. C57BL/6 (n = 9) mice were treated with vehicle or the AR antagonist enzalutamide for 1 week or 2 weeks (n = 3 each). Male ICR/scid mice (n = 8) were treated with vehicle (n = 4), enzalutamide or the androgen synthesis inhibitor abiraterone acetate for 10 days (n = 2 each). IHC demonstrated no apparent reduction in the TMPRSS2 staining intensity in the prostate glands post enzalutamide or abiraterone treatment compared with the vehicle controls (Fig. 1a–b). The lack of enzalutamide-induced downregulation of TMPRSS2 protein was observed in both young (3 months old) and old (16 months old) C57BL/6 mice (n = 9 each). Next, we evaluated the role of androgen in regulating TMPRSS2 expression in human PCa cell lines. Western blot analysis showed no reduction in the TMPRSS2 protein abundance in LNCaP or 16D PCa cells by androgen deprivation or antiandrogen treatment, despite a significant decrease in the mRNA abundance after 48 h of enzalutamide treatment (Fig. 1c–d). Next, we examined the expression of TMPRSS2 in LNCaP xenografts and a hormone sensitive human PCa PDX model after castration or castration + enzalutamide treatment. Immunostaining for TMPRSS2 protein in LNCaP xenografts and the PDX tumors showed no apparent reduction following castration or castration + enzalutamide treatment (Fig. 1e–f). Additionally, TMPRSS2 expression was retained in two cases of AR-negative small cell carcinoma of prostatic origin, indicating AR-independent TMPRSS2 expression in this tumor type (Supplementary Fig. 1a). Together, our results indicate that TMPRSS2 protein expression in benign prostate epithelium and prostatic carcinoma was likely regulated by AR-independent mechanisms, although TMPRSS2 mRNA expression was AR dependent.
TMPRSS2 protein expression is not androgen dependent in murine or human lungs
The effect of androgen on TMPRSS2 expression in murine lungs is controversial, partly due to the lack of validated anti-TMPRSS2 antibodies for IHC in early studies.7,8 To assess TMPRSS2 protein expression using IHC, we used the Abcam rabbit anti-TMPRSS2 antibody and mouse anti-TMPRSS2 antibody obtained from the Nelson Laboratory at the University of Washington. The review of IHC staining of male human lung tissue showed the presence of AR-positive cells in the bronchial respiratory epithelium and the stroma of alveolar septae. AR positivity was sparse in the alveolar pneumocytes (Supplementary Fig. 2a). TMPRSS2 was diffusely expressed by the bronchial respiratory epithelium, with the staining enriched at the ciliated apical border. ACE2 positivity was rarely detected at the apical border of the bronchial epithelium (Supplementary Fig. 2a–b). TMPRSS2 and ACE2 were expressed by alveolar pneumocytes, with the morphology consistent with type II pneumocytes and macrophages. AR-positive cells in the bronchial epithelium often co-expressed TMPRSS2 and occasionally co-expressed ACE2, while co-expression of AR with TMPRSS2 or ACE2 was rare in alveolar pneumocytes (Supplementary Fig. 2b). In male mice, AR and TMPRSS2 positivity was detected in the alveolar stromal cells, pneumocytes, and rarely in the bronchial epithelium. ACE2 was expressed by both pneumocytes and the bronchial epithelium, with strong staining at the apical border of the bronchial epithelium. Furin was positive in the smooth muscle bundles surrounding the bronchioles, vascular endothelium, and alveolar pneumocytes, and it was weakly positive in the bronchial epithelium (Fig. 2c). Next, we tested the effect of an androgen antagonist and androgen deprivation on the expression levels of TMPRSS2, ACE2, and furin in murine lungs. We observed no apparent reduction in TMPRSS2, ACE2, or furin staining in murine lungs following enzalutamide treatment for 1 week or 2 weeks (n = 3 each group), regardless of the age of the mouse (Fig. 2a). Similarly, androgen deprivation by surgical castration did not reduce the staining intensity of any of these viral entry proteins in murine lungs (n = 6 each) (Supplementary Fig. 3). In agreement with the IHC results in murine studies, immunoblots from three different human lung cancer cell lines showed minimal AR expression as well as a low level of TMPRSS2 expression that was not altered by enzalutamide treatment (Fig. 2b).
Androgen regulates TMPRSS2, ACE2, and furin in murine sinonasal tissue
The infection of SARS-CoV-2 in humans first occurs in the nasal cavity and nasopharynx in the very early phase of COVID-19 disease. Subsequently, the virus spreads to the lower respiratory tract, including the bronchi and lungs, the main target organs.9–11 Accordingly, we sought to assess the potential role of androgen signaling in SARS-CoV-2 entry protein expression in the nasal cavities. First, we performed immunostaining using turbinate specimens from male patients who underwent sinus surgery. The respiratory epithelium showed a low level of AR protein expression. TMPRSS2 and ACE2 colocalized at the ciliated apical border of the respiratory epithelium (Fig. 3a). Co-expression of AR and TMPRSS2 as well as co-expression of AR and ACE2 were easily detected by dual immunostaining. Next, we assessed AR expression in the nasal mucosa of male mice by examining coronal sections of the mouse skull. In the murine nasal cavities, the dorsal portion was lined by the olfactory epithelium, and the ventral portion was lined by the respiratory epithelium. AR was weakly expressed in both the olfactory and respiratory epithelium (Fig. 3b). TMPRSS2, ACE2, and furin were all expressed at the apical border of the respiratory epithelium. TMPRSS2 was expressed in the respiratory epithelium but not in the olfactory epithelium. Co-expression of AR and TMPRSS2 was detected in the respiratory epithelium, as shown in Figure 3b, with the inset showing colocalization of AR and TMPRSS2 in the same ciliated columnar cells. ACE2 was expressed in both the respiratory and olfactory epithelium, with a stronger expression in the olfactory epithelium (Fig. 3b, 4a). Furin was diffusely expressed in the mucosa of the entire nasal cavity. Interestingly, murine lacrimal glands showed a strong expression of AR, TMPRSS2, ACE2, and furin; whereas the minor salivary glands surrounding the respiratory sinus strongly expressed AR, TMPRSS2, and furin (Fig. 4). Next, we evaluated the effects of ADT on the abundance of these proteins in the sinonasal tissue by treating mice with mock castration or surgical castration (n = 6 in each group). In the castrated mice, the staining intensity of AR, TMPRSS2, ACE2, and furin was markedly reduced in the lacrimal glands, and it was mildly reduced in the nasal epithelium and minor salivary glands compared with that of the control mice (Fig. 4a). Immunoblots of mouse nasal mucosa from the same set of mice demonstrated a mild reduction of TMPRSS2 expression in the castrated mice (Fig. 4b). Additionally, we treated mice with the androgen antagonist enzalutamide or bicalutamide (n= 3 each) for 1 week. AR blockade was associated with a mild reduction of TMPRSS2, ACE2, and furin expression in the mouse nasal mucosa, as detected by western blot and IHC (Fig. 4c, Fig. 4). Table 1 summarizes all experiments that were conducted in this study to assess the role of androgen in modulating the expression of viral entry proteins.
Table 1Summary of results by tissue type and treatment modality
| Tissue/Cell Type | Treatment | Reduced Expression Detected by IHC (or WB)
|
|---|
| TMPRSS2 | ACE2 | Furin | AR |
|---|
| Mouse | | | | | |
| Prostate | Enzalutamide or abiraterone | No | | | |
| Lungs | Castration or enzalutamide | No | No | No | No |
| Sinonasal mucosa | Castration or enzalutamide | Yes (IHC&WB) | Yes | Yes | Yes |
| Lacrimal glands | Castration or enzalutamide | Yes | Yes | Yes | Yes |
| Minor salivary glands of sinus | Castration or enzalutamide | Yes | No | Yes | Yes |
| Human | | | | | |
| Prostate | | | | | |
| Prostate cancer cell lines | | | | | |
| LNCaP | Castration ± enzalutamide | No (WB) | | | |
| 16D | Enzalutamide or apalutamide | No (WB) | | | |
| HSPC xenografts | | | | | |
| LNCaP xenograft | Castration ± enzalutamide | No | | | |
| Patient PDX | Castration ± enzalutamide | No | | | |
| Lung | | | | | |
| Lung cancer cell lines | | | | | |
| A549 | Enzalutamide | No (WB) | | | No (WB) |
| H441 | Enzalutamide | No (WB) | | | No (WB) |
| H2170 | Enzalutamide | No (WB) | | | No (WB) |
Sample inadequacy prohibited IHC evaluation for NP epithelium collected from HITCH patients
Next, we sought to examine the potential antiviral effect of ADT in male COVID-19 patients. First, we established the protocol of NP cell block preparation and subsequent IHC staining using NP swabs obtained from healthy male donors (Supplementary Fig. 5a). The NP swab generated abundant respiratory epithelial cells, with most cells strongly positive for TMPRSS2 and a small subset of cells weakly positive for AR and ACE2. Subsequently, we collected paired NP swabs from HITCH trial patients at hospital day 1 (just prior to medical castration) and day 8 (one week after medical castration). Unexpectedly, most of the NP samples obtained from the HITCH patients generated few epithelial cells; therefore, there were insufficient cells for IHC evaluation. In rare NP samples with good cellularity, we were able to detect the co-expression of viral guide RNA and TMPRSS2 in ciliated epithelial cells (Supplementary Fig. 5b). Paired day 1/day 8 samples from two trial patients showed no apparent changes in the TMPRSS2 staining intensity in rare NP cells (Supplementary Fig. 5c). Further optimization of the methodology was not able to increase the cellularity of the patient samples. Thus, we discontinued NP swab collection, given the risk of disease contraction during the sample collection and handling.
Discussion
Randomized clinical trials have failed to show that ADT improves the clinical outcomes of hospitalized male COVID-19 patients.4,5,12 Murine studies have reported conflicting data on androgen-mediated regulation of the expression of viral entry proteins in the lungs.6–8,13,14 In our IHC survey of mouse and human tissues, we detected the co-expression of AR and viral entry proteins in sinonasal tissues and the bronchial epithelium, while the co-expression was rarely detected in the pulmonary alveolar tissue. In the mouse studies, castration and AR antagonist treatment were associated with the reduced expression of viral entry proteins in the sinonasal tissue but failed to do so in the lungs.
Our observations in the murine experiments do not align with prior studies that demonstrated androgen-mediated TMPRSS2 and ACE2 expression in the lungs.6,7 The discrepancy is likely due to the difference in detection methods. Qiao et al.5 measured TMPRSS2 expression using RNA sequencing and RNA in-situ hybridization. The authors did not measure TMPRSS2 protein expression in murine or human lungs due to the lack of a suitable IHC antibody. Likewise, they showed co-expression of AR and viral RNA in murine and human lungs using in-situ hybridization dual staining. Importantly, the transcript and protein levels of many genes are poorly correlated, including for AR-regulated genes. In support of this notion, enzalutamide reduced TMPRSS2 mRNA expression but did not reduce the TMPRSS2 protein levels in PCa cell lines (Fig. 1c–d). In our dual IHC staining experiments, the co-expression of AR and ACE2 was rare in the human alveolar epithelium (Supplementary Fig. 2b). In line with our findings, Baratchian et al. found that treatment with enzalutamide did not decrease pulmonary TMPRSS2 or ACE2 protein expression in male mice.13 Similarly, Li et al. have reported that enzalutamide treatment failed to downregulate TMPRSS2 expression in mouse lungs and human lung organoids. Moreover, they observed that enzalutamide treatment did not inhibit SARS-CoV-2-driven entry into lung cells in mouse models.8 Similarly, a recent study has shown that enzalutamide treatment did not suppress TMPRSS2 mRNA expression and had no impact on SARS-CoV-2 infection in differentiated human bronchial epithelial cells.14
In our study, the co-expression of AR with TMPRSS2 or ACE2 was detected in human and murine sinonasal mucosa (Fig. 3–4). Castration or AR antagonist treatment downregulated the expression of TMPRSS2, ACE2, and furin in murine sinonasal tissue. Notably, the AR expression in the lacrimal glands and minor salivary glands of the sinus was much stronger compared with that in the sinonasal epithelium, indicating that those adjacent exocrine glands are more sensitive to ADT. While the nasal epithelium is a putative primary target for SARS-CoV-2 replication in the early stage of COVID-19,9–11,15 recent studies have shown that the salivary glands and lacrimal glands are potential primary targets in early COVID-19.16–20 The lacrimal glands and ducts may serve as a part of the ocular route of viral infection.16,21 The salivary glands are potential viral reservoirs for COVID-19 asymptomatic infection.19,22,23 Based on these findings, we speculate that ADT is potentially effective in men with early COVID-19, when the virus infects and replicates in the sinonasal tissue and adjacent organs. Nevertheless, our study has several limitations that must be addressed. We did not perform a SARS-CoV-2 viral infection experiment in mice, which would require transduction of humanized ACE2. Further, such experiments would require Biosafety Level 3 laboratories, which was not feasible during the execution of our study. In addition, we were not able to obtain evidence of AR-mediated TMPRSS2 expression in human NP mucosa due to inadequate NP swab samples obtained from patients in the HITCH study.
The findings from our study implied a role of ADT in the early NP stage of COVID-19 but not in the pneumonia stage. This observation partially explains the failure of ADT in hospitalized men with COVID-19 in clinical trials, including the HITCH trial. The negative results of ADT in hospitalized patients may be traced to multiple factors. For instance, the HITCH trial reported reduced serum testosterone levels in the placebo group at day 8 and day 15, leading to a smaller difference in the serum testosterone levels between the degarelix group and the placebo group.4 Men with critical illness frequently have decreased serum testosterone levels, through a decrease in adrenal and gonadal androgen synthesis.24–26 This observation further argues against the utility of ADT in late COVID-19. As such, there may be a limited window for ADT to be beneficial, i.e., when the viral infection mainly involves the nasopharynx and when the patients have normal testosterone levels. To test the benefit of ADT in early COVID-19, Cadegiani et al. treated male COVID-19 outpatients with a short course of androgen blockade (ClinicalTrials.gov Identifier: NCT04446429; EAT-DUTA AndroCoV trial in Brazil).27–29 However, the benefit of ADT in early COVID-19 remains inconclusive, and we are awaiting results from independent trials.
Supporting information
Supplementary material for this article is available at https://doi.org/10.14218/JCTP.2022.00031 .
Supplementary Fig. 1
TMPRSS2 protein expression in small cell carcinoma of prostatic primary.
Representative images of TMPRSS2 IHC of metastatic small cell carcinoma of prostate origin in a patient with metastatic prostate cancer post ADT treatment (Left: 40× magnification; Right: 200× magnification).
(PDF)
Supplementary Fig. 2
AR expression in adult male human and murine lungs.
(a) Representative images of normal male human lungs stained for AR, TMPRSS2, and ACE2. Top panel: bronchiole; Bottom panel: alveoli (200× magnification). (b) Representative images of human lungs stained using dual IHC: Left upper: co-expression of AR (blue) and TMPRSS2 (red) in bronchial epithelium; Right upper: rare co-expression of AR (red) and ACE2 (brown) in bronchial epithelium; Left bottom: AR (red) and TMPRSS2 (brown) detected in different cells in alveolar tissue; Right bottom: AR (red) and ACE2 (brown) detected in different cells in alveolar tissue (200× magnification). (c) Representative images of murine lungs stained for AR, TMPRSS2, ACE2 and Furin (400× magnification).
(PDF)
Supplementary Fig. 3
No apparent changes in TMPRSS2, ACE2, and furin expression in male murine lungs after castration.
Representative images of lung tissue stained for TMPRSS2, ACE2, and furin, from mice post mock-castration and castration (n = 6 each) (200× magnification).
(PDF)
Supplementary Fig. 4
Androgen antagonist treatment was associated with mild reduction of expression of viral entry proteins in sinonasal mucosa in male mice.
Representative images of respiratory or olfactory epithelium stained for TMPRSS2, ACE2, furin, and AR, after the mice were treated with vehicle or enzalutamide for 1 week or 2 weeks (n = 4 in each group) (200× magnification).
(PDF)
Supplementary Fig. 5
AR and TMPRSS2 expression in male human nasopharyngeal (NP) cells.
(a) Representative images of for AR and TMPRSS2 IHC of NP cells collected from healthy male donors (arrow: AR+ cells, TMPRSS2 positivity on the apical membrane) (400× magnification). (b) Representative images of NP cells collected from a HITCH trial patient, stained using dual IHC & ISH stains for TMPRSS2 protein (brown) and SARS-CoV-2 viral gRNA (red) (oil lens, 1,000× magnification). (c) Representative images of TMPRSS2 IHC of scant NP cells collected from two HITCH trial patients at Day 1 prior to degarelix and Day 8 post degarelix treatment (400× magnification).
(PDF)
