Introduction
Thyroid nodules are very common and may occur in up to 50% of adults.1 With the advancement of imaging technologies, more thyroid nodules are detected in asymptomatic patients, either during routine check-ups or staging for tumors other than the thyroid. Most thyroid nodules are benign. Thyroid fine-needle aspiration (FNA) has been established as a first-line triaging tool after the ultrasound examination. The thyroid Bethesda Reporting System, first published in 2010, established a standardized, category-based reporting system.2 Since its first publication, the reporting system has been widely adopted by cytopathologists in the United States and worldwide. The reporting system has six categories with clearly stated diagnostic criteria, sample explanatory notes, and, more importantly, clinically implied risk of malignancy (ROM) for each category and management guidance.
In 2017, the histologic diagnostic category of noninvasive follicular thyroid neoplasm with papillary-like nuclear features (NIFTP) was introduced, which impacted the ROM of the Bethesda Thyroid Reporting System, especially the indeterminant categories, including atypia of undetermined significance (AUS), (suspicious for) follicular neoplasm (S/FN), and suspicious for malignancy (SM) categories because follicular patterned lesions with nuclear features of papillary thyroid carcinoma are no longer always malignant. The second edition of the Bethesda Thyroid Reporting System was then published in 2017 to adjust the ROM of each diagnostic category and add explanatory notes to state that certain SFN and SM may represent the newly established NIFTP in histologic diagnosis.3 The second edition also added molecular testing to manage lesions in indeterminant categories.4
Since the publication of the second edition, new data from prospective studies on ROM have been published in the literature.5 Molecular tests are refined and updated.6 The new American Thyroid Association (ATA) guideline will be published in 2023. The new WHO Classification of Thyroid Neoplasms has proposed new terminology.7 Accordingly, the third edition of the Bethesda Thyroid Reporting System will be published in June 2023.8 The third edition focuses on simplifying diagnostic categories with single names for each category, adopting the new histologic terminologies according to the 2022 WHO Classification on Thyroid Neoplasms (Table 1), and updating the risk of malignancy for each category (Table 2). Application of TBSRTC in pediatric thyroid nodules is added in the third edition, as well as two new chapters, including “Clinical Perspectives and Imaging studies” and “Use of Molecular and other Ancillary Tests.” This review will provide an updated summary of the reporting system. Potential diagnostic pitfalls and molecular testing are also discussed.
Table 1The Bethesda System for Reporting Thyroid Cytopathology*
| I | Nondiagnostic | Cyst fluid only; Virtually acellular specimen; Other (obscuring blood, clotting artifact, drying artifact, etc.) |
|---|
| II | Benign | Consistent with follicular nodular disease (includes adenomatoid nodule, colloid nodule, etc.); Consistent with chronic lymphocytic (Hashimoto) thyroiditis in the proper clinical context; Consistent with granulomatous (subacute) thyroiditis; Other |
| III | Atypia of Undetermined Significance | AUS-nuclear atypia; AUS-Other |
| IV | Follicular neoplasm | Specify if oncocytic (Hurthle cell) type |
| V | Suspicious for Malignancy | Suspicious for papillary thyroid carcinoma; Suspicious for medullary thyroid carcinoma; Suspicious for metastatic carcinoma; Suspicious for lymphoma |
| VI | Malignant | Papillary thyroid carcinoma; High-grade follicular derived carcinoma; Medullary thyroid carcinoma; Undifferentiated (anaplastic) carcinoma; Squamous cell carcinoma; Carcinoma with mixed features; Metastatic malignancy; Non-Hodgkin lymphoma; Other |
Table 2The Bethesda System for Reporting Thyroid Cytopathology: implied risk of malignancy (ROM) and recommended clinical management*
| Diagnostic category | ROM average% (range) | Usual management |
|---|
| Nondiagnostic | 13 (5–20) | Repeat with ultrasound guidance |
| Benign | 4 (2–7) | Clinical and sonographic follow-up |
| Atypia of Undetermined Significance | 22 (12–30) | Repeat FNA, molecular testing, diagnostic lobectomy, or surveillance |
| Follicular neoplasm | 30 (23–34) | Molecular testing, diagnostic lobectomy |
| Suspicious for Malignancy | 74 (67–83) | Molecular testing, lobectomy, or near-total thyroidectomy |
| Malignant | 97 (97–100) | Lobectomy or near-total thyroidectomy |
The reporting system (Table 1)
Non-diagnostic
Diagnostic criteria
Fail to meet adequacy criteria (6 groups with at least 10 well-preserved, well-stained cells in each group, preferably on a single slide);
Poorly prepared, poorly stained, or significantly obscured follicular cells;
Cyst fluid, with or without histiocytes, and fewer than six groups of ten benign follicular cells.
Exceptions:
Any atypia;
Solid nodule with inflammation (thyroiditis);
Abundant colloid (colloid nodules).
In the third edition of TBSRTC, “Unsatisfactory” is removed from the name of the category. A cyst fluid-only specimen is non-diagnostic but may be clinically adequate in a proper clinical context (ultrasound showing a simple unilocular cyst). Examples of non-diagnostic thyroid FNA are illustrated in Figure 1.
Differential diagnosis and potential pitfalls
It is vital to recognize thick and watery colloids and not mistake cyst fluid and blood serum as thin colloid and skeletal muscle as thick colloid (Fig. 2).
Ancillary testing
The role of molecular testing in this category is unknown, and molecular testing is usually not performed. If performed, the result should be interpreted cautiously due to potential false negative results.
Risk of malignancy (ROM) and clinical management recommendation
There is no updated data on ROM upon publishing the third edition of TBSRTC. The risk of malignancy in the non-diagnostic category is estimated at 13% (5–20%). The usual management is to repeat FNA with ultrasound guidance. However, there is no definitive recommended time interval for repeating an FNA in patients with a non-diagnostic interpretation of thyroid FNAs.
Benign
Diagnostic criteria
Follicular nodular disease (FND)
The term FND was introduced in the 2022 WHO Classification of Thyroid Neoplasms. It encompasses a spectrum of benign thyroid follicular lesions, including colloid nodules, hyperplastic nodules, and adenomatous ones. Diagnostic criteria in thyroid FNAs include:
A variable amount of colloid and cellularity (meeting the criteria for adequacy if not abundant colloid):
Colloid is green or orange-pink on Pap stains and blue-violet on Diff-Quik stains. The thin watery colloid is shiny and forms a thin membrane with frequent folds giving an appearance of “waves” or “crazy pavement.” Thick colloid has a hyaline appearance and often with cracking (“stained glass cracking” appearance).
Follicular cells arrange in flat sheets, spherules, or small tissue fragments (Fig. 3);
Follicular cells are small (similar size as adjacent red blood cells) and evenly spaced with no nuclear enlargement, crowding, or overlapping;
The cells have round to oval nuclei, evenly granular chromatin, and scant or moderate amount of cytoplasm.
Lymphocytic thyroiditis (LT)
LT includes several forms of thyroiditis, predominantly chronic lymphocytic thyroiditis (Hashimoto thyroiditis). Accurate subtyping of LT requires clinical and serologic correlations. Diagnostic criteria include:
Polymorphous population of lymphocytes admixed with follicular cells/oncocytic cells (Fig. 4);
Prominent fibrosis and decreased cellularity may be present;
A minimum number of follicular cells for adequacy is not required in the setting of LT.
The benign category should account for 60–70% of all thyroid FNA diagnoses. The success of the TBSRTC relies on the success of this category to prevent unnecessary surgeries.
Differential diagnosis and potential pitfalls
Follicular cells may appear as individual stripped (“naked”) nuclei and should not be mistaken as lymphocytes. The mere presence of microfollicles does not preclude a diagnosis of FND.9,10 When microfollicles are less than 10% of the follicular cell population, and microfollicles are made of cells similar to those in adjacent flat sheets and do not show nuclear enlargement and overlapping, they still represent features of a benign follicular nodule (Fig. 2c).
Follicular cells trapped in blood clots may show artifactual crowdedness or microfollicles. If other areas of the slides show benign findings, the case should be considered benign.
When oncocytic cells are a predominant feature, it should not be automatically considered oncocytic neoplasm. When oncocytic cells are associated with background colloid, lymphocytes, or oncocytic cells appear uniform, the lesion should be diagnosed as benign.11
Ancillary testing
A diagnosis of a benign thyroid nodule does not need additional molecular testing.
Risk of malignancy (ROM) and clinical management recommendation
ROM of the benign category is approximately 4% (2–7%). Conservative follow-up, including periodic clinical and radiologic examinations, is recommended.
Atypia of undetermined significance
The third edition of TBSRTC simplified the terminology and removed “follicular lesion of undetermined significance (FLUS)” from the diagnostic term. It also re-organized AUS scenarios and formalized subclassification of AUS as AUS-nuclear atypia and AUS-other.
Diagnostic criteria4
AUS - nuclear atypia (Fig. 5)
Focal nuclear atypia: Rare cells show nuclear enlargement, nuclear pallor, and irregular nuclear membrane. Intranuclear pseudoinclusions are absent.
Extensive but mild nuclear atypia: Many cells show mildly enlarged nuclei, slightly pallor chromatin, and only limited irregular nuclear membrane. Intranuclear pseudoinclusions are absent;
Atypical cyst-lining cells: In a typical setting of cyst-lining cells, some cells show more elongated nuclei, nuclear grooves, chromatin pallor, or rare intranuclear pseudoinclusions;12
“Histiocytoid” cells: These cells raise suspicion for cystic papillary thyroid carcinoma. The atypical histiocytoid cells are larger than the background histiocytes. Cytoplasm is denser without hemosiderin or microvacuoles. Large cytoplasmic vacuoles may be present;13,14
Nuclear and architectural atypia: Scantly cellular specimens show microfollicular patterns, with follicular cells showing nuclear enlargement, nuclear pallor, and irregular nuclear membrane. This pattern raises suspicion about NIFTP.
AUS – other
Architectural atypia: A paucicellular specimen contains follicular cells in three-dimensional groups or microfollicles. Colloid is scant;
Oncocytic atypia: A sparsely cellular specimen contains exclusively oncocytes and minimal colloid, or a cellular specimen exclusively contains oncocytes in the clinical setting of lymphocytic thyroiditis;
Atypia, not otherwise specified: There are nuclear changes not suggestive of papillary thyroid carcinoma, including nuclear enlargement and prominent nucleoli, or there are psammomatous calcifications with no cellular features of PTC;
Atypical lymphoid cells rule out lymphoma
Differential diagnosis and potential pitfalls
AUS should be reserved for cases where the findings raise concerns for papillary thyroid carcinoma, follicular neoplasm, or other malignancy. However, the quantity and/or quality of atypia is insufficient for a more definitive interpretation. For this entity to remain a valid and valuable category, AUS should not be over-used.15 Cases with scant follicular groups trapped in fibrin clots with crowded architecture or focal nuclear pallor should be called non-diagnostic instead of AUS. A cellular aspirate with predominant benign findings and only focal microfollicles should be called benign, not AUS. AUS serves as a good quality measure. The second edition of TBSRTC proposes that AUS should remain < 10% of all thyroid diagnoses. Alternatively, an AUS/malignant ratio not exceeding 3 is suggested as a good quality measure for a cytopathology lab.16
Ancillary testing
Molecular testing is a recommended clinical management step for AUS but not reflex testing for AUS. Molecular testing may further classify thyroid lesions into AUS diagnosis as low-risk or high-risk lesions. While low-risk lesions may return to surveillance, high-risk lesions require a surgical referral (lobectomy or total thyroidectomy).
Molecular alterations considered high-risk for thyroid cancers usually include BRAFV600E mutations, RET/PTC fusions, ALK fusions, NTRK fusions, and p53 mutations. Those associated with low to intermediate risks include BRAFK601E mutation, RAS mutations, PAX8-PPARG fusion, and THADA fusions.17–19 Several molecular test platforms are available such as Afirma and ThyroSeq.20 A recent study showed no statistically significant difference in diagnostic performance among different tests; however, molecular test did successfully prevent unnecessary diagnostic surgeries in a significant percentage of patients who had an indeterminant thyroid FNA diagnosis.21
Risk of malignancy (ROM) and clinical management recommendation
The average ROM of the AUS category is 22% (13–30%).7 Patients with a diagnosis of AUS on their thyroid lesions should be managed conservatively. Clinical management recommendation includes repeat FNA, molecular testing, diagnostic lobectomy, or surveillance.
Follicular neoplasm
The third edition of TBSRTC simplified the terminology of this category and removed “Suspicious for follicular neoplasm (FN)” from the diagnostic term. Follicular neoplasm represents an infrequent diagnosis (approximately 7%) in thyroid FNAs.
Diagnostic criteria4
Architectural patterns: microfollicular, crowded three-dimensional, and trabecular patterns;
Cytologic findings (typical FN scenario):
round nuclei, clumpy or mildly hyperchromatic chromatin;
inconspicuous nucleoli;
lack of nuclear clearing, nuclear grooves, intranuclear pseudoinclusions;
Cytologic findings (atypical features, potential NIFTP/FVPTC scenario):
Mild nuclear enlargement;
Nuclear pallor/clearing;
Irregular nuclear membrane (nuclear grooves);
Absent or rare intranuclear pseudoinclusions.
Follicular pattern, lack of true papillae
Follicular patterned lesions with typical cytologic features represent a traditionally typical follicular neoplasm scenario (Fig. 6a). The corresponding histologic findings include follicular adenoma, adenomatous nodule, or rarely follicular carcinoma. Distinction among these three entities cannot be made in cytology. Follicular patterned lesions with atypical cytologic features such as nuclear pallor, irregular nuclear membrane, and mild nuclear enlargement represent a potential NIFTP/FVPTC scenario (Fig. 6b).22 The third edition of TBSRTC increases the awareness of NIFTP in cytologic diagnosis. When NIFTP is suspected, the lesion should be put in the follicular neoplasm category, not the suspicious for malignancy/malignant category, to avoid overtreatment with aggressive surgery.
Differential diagnosis and potential pitfalls
The hallmark of FN is the architectural pattern of microfollicles. It has been proposed that microfollicle designation be limited to crowded flat groups of less than 15 follicular cells arranged in a circle that is at least two-thirds complete.23 Sometimes, crowded follicular cells form ribbons (trabecular pattern). Not all follicular structured groups represent microfollicles. The key defining features of microfollicles are nuclear crowding and overlapping. The mere presence of microfollicles does not warrant a diagnosis of FN if it represents a small percentage of the follicular groups seen or is identified in a scantly cellular specimen.
When colloid is scant or absent, the possibility of parathyroid adenoma or metastatic neuroendocrine tumor should be raised. A review of the clinical history and imaging findings may be helpful. Immunohistochemical staining is useful if there is enough cellular material on the cellblock.
Ancillary testing
Follicular patterned neoplasm, including follicular adenoma, follicular carcinoma, NIFTP, and FVPTC, share some common molecular alterations, including point mutations in the RAS gene family and PPARG rearrangements.24 Molecular testing is one of the recommended management steps. It can help further stratify or omit surgery (see discussion under AUS).
Risk of malignancy (ROM) and clinical management recommendation
ROM of the follicular neoplasm category is approximately 30% (23–34%). Clinical management recommendation includes molecular testing and diagnostic lobectomy.7
Oncocytic follicular neoplasm (OFN)
In the 3rd edition of TBSRTC, the term Hurthle cell is replaced by Oncocyte, corresponding to the changes in the 2022 WHO Thyroid Neoplasm book. The diagnostic criteria remain the same:
Smears are cellular and composed of almost exclusively oncocytes (Fig. 7):
Enlarged central or eccentrically located nuclei with prominent nucleoli;
Abundant finely granular cytoplasm;
Binucleation common;
Presence of atypia/dysplasia:
Small cells with a high nuclear/cytoplasmic ratio (small cell dysplasia);
Large cells with at least two times variability in nuclear size (large cell dysplasia);
Oncocytes are dispersed as single cells or sometimes form crowded groups;
No or scant colloid;
Lack of background lymphocytes or plasma cells.
A scantly cellular specimen composed of exclusive oncocytes should be diagnosed as AUS. A cellular specimen composed of exclusive oncocytes without dysplasia may be called benign if an abundant colloid exists.25 If there is no accompanying colloid, while some may still diagnose such cases as benign, others may call it oncocytic follicular neoplasm. In contrast, cellular specimens composed of exclusive oncocytes with dysplasia, even in the presence of abundant colloid (usually watery colloid), should be categorized as OFN.26 A follicular neoplasm case with focal oncocytes should be classified as follicular neoplasm if the oncytes population is less than 75%. In the clinical context of lymphocytic thyroiditis or follicular nodular disease, the presence of pure oncocytes without lymphocytes (former) or normal follicular cells (later) may be diagnosed as AUS instead of OFN to avoid unnecessary surgery. An explanatory note commenting that the lesion may represent oncocytic hyperplasia in the setting of LT or FND is helpful.
Suspicious for Malignancy
The suspicious category is used when cytomorphologic features raise a strong suspicion of malignancy but are quantitatively or qualitatively insufficient for a definitive conclusive diagnosis.
Diagnostic criteria4
Suspicious for papillary thyroid carcinoma (Fig. 8)
Patchy nuclear changes pattern:
Unremarkable follicular cells are admixed with cells showing nuclear enlargement, nuclear pallor, nuclear grooves, and fine chromatin;
Intranuclear pseudoinclusions are scant or absent;
Papillary architecture and psammoma bodies are absent;
Incomplete nuclear changes pattern:
Generalized nuclear enlargement, nuclear pallor, and nuclear grooves;
Irregular nuclear membrane and intranuclear pseudoinclusions are scant or absent;
Papillary architecture and psammoma bodies are absent;
Sparsely cellular specimen pattern:
Cystic degeneration pattern;
Background of cystic debris and macrophages;
Nuclear enlargement and nuclear pallor;
Atypical histiocytoid cells with cytoplasmic vacuoles.
Papillary architecture and psammoma bodies are absent.
Suspicious for medullary thyroid carcinoma
Discohesive monomorphic cells with high nuclear/cytoplasmic ratio; smudged chromatin due to poor preservation;
Small fragments of amorphous material, indeterminant between colloid and amyloid;
Insufficient material for ancillary immunohistochemical staining to confirm the diagnosis.
Suspicious for lymphoma
Abundant monomorphic small- to medium-sized lymphocytes; however, with no immunophenotyping support from flow cytometry;
Scant atypical large lymphocytes, insufficient material for ancillary immunocytochemistry or flow cytometry study.
Suspicious for metastatic carcinoma and others
Scant atypical cells are present, and there is insufficient material for additional immunohistochemical staining to confirm/exclude a definitive diagnosis.
Differential diagnosis and potential pitfalls
The suspicious category falls between AUS and Malignant categories; therefore, differential diagnosis usually includes AUS and Malignant. The distinction may be subjective and varies among pathologists on the threshold of quantity and quality. When uncertain if the atypical cytologic findings could represent benign findings, the diagnosis should remain AUS. When one is almost certain of the malignant nature of the lesion but lacks that one last thing quantitatively or qualitatively, the diagnosis should be suspicious for malignancy.
Differential diagnosis of suspicious for lymphoma includes lymphocytic thyroiditis and sampling of an adjacent benign lymph node.
Ancillary testing
Molecular testing has been shown to increase ROM from about 74% to 95% with positive results.27 It identifies a subset of high-risk cancers, helps optimize the extent of surgery, and facilitates individualized patient care.28
Ancillary testing is essential in working up non-PTC type malignancies in the thyroid. ROSE (rapid onsite specimen evaluation) can raise the possibility of non-PTC type malignancies and anticipate the need for ancillary testing. If ROSE is not routinely performed for thyroid FNAs, it is crucial to collect extra passes for cellblocks if the clinical suspicion for non-PTC type malignancy is high, for example, in patients with elevated serum calcitonin or in patients to rule out metastasis. If there is a concern for lymphoma in patients with chronic lymphocytic thyroiditis, samples should be collected for flow cytometry.
Risk of malignancy (ROM) and clinical management recommendation
ROM of this category is 74% (67–83%). Clinical management recommendation includes molecular testing, lobectomy, or near-total thyroidectomy.
Malignant
Diagnostic criteria
Papillary thyroid carcinoma and subtypes
Moderately to markedly cellular;
Cohesive groups arranged in flat sheets/monolayers, finger-like papillary fragments;
microfollicles and swirls (Fig. 9);
Various degrees of nuclear crowding and overlapping
Typical PTC nuclear features:
Convoluted nuclear contour (Fig. 10);
Intranuclear cytoplasmic pseudoinclusions (INCIs);
Nuclear grooves;
Pale chromatin;
Nuclear enlargement;
Small nucleoli, single or multiple, often eccentric;
Cytoplasmic changes: granular, eosinophilic, squamoid, oncocytic, histiocytoid;
Colloid (dense bubblegum-like or watery) is usually scant or absent;
Psammoma body may be present in a subset (4–20%) of cases, but it is not pathognomonic for PTC (positive predictive value ∼50%);
Multinucleated giant cells and histiocytes may be present;
Single-cell predominant pattern is uncommon and raises the possibility of medullary, poorly differentiated, and undifferentiated carcinomas;
Mitosis, necrosis, and markedly pleomorphic/bizarre cells suggest high-grade subtypes of differentiated carcinoma and raise the possibility of less common tumors, such as poorly differentiated and undifferentiated (anaplastic) carcinomas and metastasis.
Some PTC subtypes may show attenuated or exaggerated nuclear features. For example, follicular subtype PTC usually demonstrates pale chromatin and variably enlarged nuclei. However, ICNIs and grooves can be rare or absent. These features overlap with NIFTP. As a result, a small subset (estimated 3–4%) of thyroid FNAs diagnosed as PTC will turn out to be NIFTP in histology.29,30 Conversely, tall cell subtype PTC generally demonstrates exaggerated PTC nuclear features with prominent groves and INCIs. Besides, PTC cytoplasm can show distinct patterns depending on the subtypes.
Medullary carcinoma
Cellular sample with single cells and syncytial groups (Fig. 11);
Heterogenous tumor cells: mixed polygonal, round, plasmacytoid, and spindle cells;
Salt and pepper chromatin with inconspicuous nucleoli;
Mild to moderate nuclear pleomorphism;
Binucleation is common;
Diffuse pleomorphism, mitosis, and necrosis are unusual;
INCIs may be present, indistinguishable from PTC INCIs;
Amyloid is present in about one-third to one-half of medullary carcinoma aspirates; it can mimic colloid;
Intracytoplasmic vacuoles and melanin-like pigments have been rarely reported;31
Small cell subtype MTC can mimic small cell carcinomas of other origins but is rare;32
The presence of colloid does not rule out MTC.
Medullary thyroid (MTC) carcinoma is a rare thyroid malignancy and is challenging to diagnose by cytomorphology alone. Preprocedural planning and ancillary techniques, including ROSE, needle rinse for calcitonin level by chemistry, and immunohistochemistry, can significantly increase the diagnostic rate for MTC.33
High-grade follicular-derived carcinoma
The New WHO classification proposed the category of high-grade follicular-derived carcinoma to include poorly differentiated thyroid carcinoma (PDTC) and differentiated high-grade thyroid carcinoma (follicular carcinoma or papillary carcinoma). It is a high-grade follicular-derived neoplasm with biological features between differentiated thyroid carcinoma and undifferentiated (anaplastic) carcinoma. Poorly differentiated carcinoma (insular carcinoma) lacks conventional nuclear features of PTC and is characterized by uniform small, convoluted nuclei with a high nuclear to cytoplasmic ratio. Mitosis and necrosis are often present (Fig. 12). Due to the non-specific nuclear features, poorly differentiated thyroid carcinoma may fall into the malignant category by cytology but requires ancillary immunohistochemistry for a definitive diagnosis.
Anaplastic (undifferentiated) carcinoma and squamous cell carcinoma of the thyroid
Anaplastic (undifferentiated) thyroid carcinoma (ATC) is rare (1%) yet, critical to diagnose. ATC is a highly aggressive thyroid cancer associated with rapid progression and poor outcomes, the median survival of 5–12 months with conventional therapy.34 Thyroid FNA is usually the first and sometimes the only tumor sample due to a large percentage of non-resectable tumors at diagnosis. The cytologic features of ATC include:
Variably cellular aspirates with predominantly isolated tumor cells (Fig. 13);
Predominant cytologic patterns include spindle, pleomorphic, squamous, epithelioid, rhabdoid, and osteoclast-like cells;35
Mitosis and necrosis are common;
Binucleated, multinucleated cells and cells with bizarre nuclei are frequently seen;
Neutrophil-rich inflammation is common and sometimes overwhelming;
Conventional PTC, follicular carcinoma, or squamous differentiation may be focally present;
Pure squamous cell carcinoma of thyroid origin is now considered a subtype of ATC.35 SCC of thyroid origin is reportedly 100% positive for PAX8.36
Carcinoma with mixed features mainly refers to mixed medullary and follicular cell-derived carcinomas that may occur occasionally. It is vital to specify components of different features and the approximate percentage of each component7
Lymphomas, metastatic tumors, and rare tumors of the thyroid
Thyroid lymphomas constitute about 5% of all thyroid malignancies.37 They are predominantly non-Hodgkin B-cell lymphomas (Fig. 14). The most common types are mucosa-associated lymphoid tissue (MALT) marginal zone lymphomas and diffuse large B cell lymphomas.37,38 Chronic lymphocytic (Hashimoto) thyroiditis is a risk factor for primary thyroid lymphomas reported in an average of 80% of primary thyroid lymphomas. FNA aspirates from lymphomas are often markedly cellular, consisting of numerous lymphocytes. Three patterns of thyroid lymphoma have been reported:39 1) a mixture of small and large lymphocytes, 2) a monotonous population of large lymphocytes, and 3) a monomorphous population of small lymphocytes. The first and third patterns can be seen in Hashimoto thyroiditis without oncocytic, follicular, and plasma cells. Like elsewhere in the body, immunophenotyping studies by immunohistochemistry and flow cytometry are essential for the diagnosis of lymphomas of the thyroid.
Metastatic tumors of the thyroid are rare. The most common sites of the primary tumor are the kidney (Fig. 14), lung, gastrointestinal tract, breast, and skin (melanoma).40 In addition, involvement by adjacent head and neck, mediastinal and esophageal tumors can occur. Rapid onsite evaluation to assess tumor morphology and triage samples for ancillary studies help improve the diagnostic yield (Table 3).
Table 3Immunohistochemistry panel for metastatic carcinoma to the thyroid
| TTF1 | PAX8 | Thyroglobulin | GATA3 | ER | CDX2 |
|---|
| PTC | + | + | + | − | −/weak+ | − |
| RCC | − | + | − | − | − | − |
| Breast carcinoma | − | − | − | + | +/− | − |
| Non-small cell lung carcinoma | + | − | − | −/+ | − | −/+ |
| Endometrial Adenocarcinoma | − | + | − | − | + | − |
| Colon Cancer | − | − | − | − | − | + |
Other even rare malignant neoplasms of the thyroid, such as salivary gland type carcinomas and thymic tumors within the thyroid, may be suggested in cytology. However, the final diagnosis is often made on histology.
Differential diagnosis and potential pitfalls
PTC vs. NIFTP
The presence of papillary architecture, psamomatous calcifications, and INCIs together are specific for PTC, whereas the predominant microfollicular pattern and absence of the above PTC features favor NIFTP or follicular subtype PTC.41 Yet, no features can reliably distinguish NIFTP from follicular subtype PTCs.
PTC vs. medullary carcinoma
Due to the rarity of MTC and morphologic overlap with PTC, medullary carcinoma can be mistaken for PTC. Intranuclear INCIs, present in about 20–50% of medullary carcinomas, are indistinguishable from those seen in PTC. Additionally, amyloid in medullary carcinoma can mimic the thick colloid seen in PTC. Nevertheless, uncommon features in PTC that raise the possibility of medullary carcinoma include predominantly single-cell pattern, mixed epithelial and spindle cell morphology, salt and pepper-like chromatin, binucleation, and plasmacytoid morphology. Nuclear groves and psammoma bodies are features favoring PTC and are uncommon in MTC. MTC express C-cell markers (calcitonin and CEA) and neuroendocrine markers (synaptophysin, chromogranin, and INSM1), which help separate MTC from its mimics (Table 4). In addition, thyroglobulin is negative in MTC.
Table 4Immunohistochemistry panel for the diagnosis of medullary carcinoma and PTC
| TTF1 | PAX8 | Thyroglobulin | Calcitonin | CEA | synaptophysin | Chromogranin |
|---|
| PTC | + | + | + | − | − | −/rare + | − |
| Medullary carcinoma | + | +/− | − | + | + | + | + |
Unusual patterns
Unusual patterns such as non-cohesive single cells, spindle cells, plasmacytoid morphology, and binucleation raise the possibility of medullary carcinoma, anaplastic carcinomas, melanoma, and lymphoproliferative processes (Fig. 14). Immunohistochemistry and clinical history are the keys to distinguish them (Table 5). Anaplastic carcinoma is often diagnosed by high-grade cytologic features and excluding the above mimickers. Sarcoma may enter the differential diagnosis when the predominant cytologic pattern is spindle cells. Primary sarcoma of the thyroid is extremely rare and is limited to case reports.42 Anaplastic carcinoma must be ruled out by cytokeratin and PAX8 immunohistochemistry before diagnosing primary thyroid sarcoma.
Table 5Immunohistochemistry panel to distinguish medullary carcinoma, anaplastic carcinoma, melanoma, and plasma cell neoplasm
| Cytokeratin | Calcitonin | CEA | Pax8 | TTF1 | Melan A | HMB45 | CD138 |
|---|
| Medullary carcinoma | + | + | +/- | +/- | + | - | - | - |
| Anaplastic carcinoma | + (focal weak) | - | -/rare + | +/- | -/rare + | - | - | - |
| Melanoma | - | - | - | - | - | + | + | - |
| Plasma cell neoplasm | - | - | | - | - | - | - | + |
Ancillary testing
Immunohistochemistry (IHC)
IHC has a limited role in diagnosing PTCs but can be critical in working up uncommon tumors such as medullary carcinoma, anaplastic carcinomas, metastatic tumors, and lymphomas. Anaplastic carcinoma tends to lose follicular markers thyroglobulin and TTF1, but PAX8 is at least focally positive in 76–79% of anaplastic carcinoma.36,43 While chromogranin seems more specific for medullary carcinoma, synaptophysin expression has been reported in various follicular neoplasms, including PTCs,44,45 therefore, synaptophysin alone cannot be used to distinguish PTC and MTC. Calcitonin and CEA are specific markers for MTC. Rare pitfalls include moderately differentiated neuroendocrine tumor (atypical carcinoid) of the larynx, which has been reported to be frequently positive for calcitonin. However, TTF1 is usually negative in laryngeal atypical carcinoid.46 Cytokeratin supports anaplastic carcinomas, ruling out sarcomas, melanoma, and lymphoproliferative processes. Reduced cytokeratin expression is most common in spindle cell anaplastic carcinoma, but at least focal weak keratin positivity has been seen in most anaplastic carcinomas.36,47
Molecular testing
Molecular testing has a limited role in diagnosing malignancy, but it has enhanced our understanding of the pathogenesis of thyroid cancers and promoted the discovery of novel therapeutics for advanced thyroid carcinomas. BRAF V600E mutation is the most frequently identified genetic alteration in PTCs. About 20–50% of anaplastic carcinomas harbor BRAF V600E mutation, often coexisting with a well-differentiated PTC component.48,49 In 2021, American Thyroid Association (ATA) updated its guidelines for anaplastic thyroid carcinoma. The new guideline highlighted emerging novel therapies for anaplastic carcinoma and underscored the importance of molecular testing to identify the actionable mutation. Specifically, BRAF testing by IHC and confirmed by molecular testing is strongly recommended for anaplastic carcinoma to facilitate anti-BRAF therapy.50 Cellblock can be used for BRAF and expanded molecular testing, but additional needle biopsies may be necessary due to scant cellularity in FNA material. Screening for germline RET proto-oncogene mutation is mandatory after diagnosing MTC, as 25% of cases of MTC are associated with germline RET mutation (MEN2 syndrome). In addition, about half of sporadic MTC harbor somatic RET mutations,51 a therapeutic target with RET inhibitors.52
Risk of malignancy (ROM) and clinical management recommendation
The risk of malignancy (ROM) for the malignant category remains unchanged, 97% on average. Reclassifying a subset of encapsulated follicular subtype PTC as NIFTP (a low-risk tumor) affects the risk of malignancy (ROM) for almost all Bethesda categories, but the effect on the malignant category is small. Nevertheless, about 3% of the malignant thyroid FNAs will prove to be NIFTP on histology. This effect generally does not apply to the non-PTC type of malignancies.
The management for most primary thyroid carcinomas is surgery by either total thyroidectomy or lobectomy, while lymphomas and metastatic tumors are treated with chemotherapy and/or radiation.
Total thyroidectomy is recommended for patients with PTCs with high-risk factors such as large size (>4 cm), extrathyroidal extension, neck lymph node involvement, bilateral nodularity, distant metastasis, and history of neck radiation. Neck lymph dissection may be necessary for high-risk patients too. Small (<4 cm) localized PTCs may be treated with partial lobectomy or total thyroidectomy. Active surveillance is an alternative for patients with microcarcinomas (< 1 cm) without lymph node metastasis or other adverse factors.
Medullary carcinoma would trigger a series of preoperative studies, including imaging to assess the extent of the disease, serum calcitonin and CEA measurement, and genetic testing for germline RET mutations. The surgery for MTC includes total thyroidectomy with neck lymph node dissection. Appropriate medical and surgical management for patients with hereditary MTC and pheochromocytoma should precede thyroidectomy. Advanced, progressive MTC may be treated with tyrosine kinase inhibitors targeting RET.
Anaplastic thyroid carcinoma is highly aggressive and lethal in most cases. Conventional treatment has been palliative care or an intensive multimodal approach. In recent years, molecular-driven novel therapeutics have been the most promising field in treating anaplastic carcinoma. The combination of dabrafenib (BRAF inhibitor) and trametinib (MEK inhibitor) was reported to lead to significant tumor regression (response rate 69%) for patients with anaplastic carcinomas that carry the BRAFV600E mutation.34,53 FDA has approved the combination for this condition.
Conclusions
The third edition of the Bethesda System for Reporting Thyroid Cytopathology further simplifies the system by having one name per category. It provides clarity for communication among pathologists, radiologists, endocrinologists, and surgeons. The modified terminology, such as follicular nodular disease and follicular oncocytic neoplasm, aligns with the terminology of the most recent WHO classification of Thyroid Tumors. The refined ROM more accurately reflects the clinical implications of each category and links to the clinical management recommendations. Future studies will further define the utilization of molecular testing in thyroid FNAs.
Abbreviations
- FNA:
fine-needle aspiration
- AUS:
atypia of undetermined significance
- LT:
lymphocytic thyroiditis
- PTC:
papillary thyroid carcinoma
- ROM:
risk of malignancy.
Declarations
Funding
None.
Conflict of interest
Fan F has been an editorial board member of Journal of Clinical and Translational Pathology since May 2021. The authors have no other conflict of interests to declare.
Authors’ contributions
Dr. Min Han contributed to the manuscript through writing and critical revision. Dr. Fang Fan contributed to the manuscript in writing, critical revision, and final submission. Both authors have contributed significantly to this study and approved the final manuscript.
